1. Blind rivet setting tool
1.1 Work capacity
Blind rivets from Ø 2.4 mm Aluminium to Ø 5 mm in all materials; blind rivets Ø 6 mm
Aluminium. BULB-TITE
®
blind rivets Ø 4.0; 5.2 mm Aluminium and steel.
1.2 Equipment/accessories
Nosepieces: 17/32 in working position
17/24; 17/27; 17/29 in the nosepiece holder
Wrench: SW 12 (cover for nosepiece holder)
Suspension loop: Concealed in housing
Battery (quick-change): 18.0 volt
Battery charger: 100 V-240 V~/50-60 Hz
1.3 Technical data
Weight: 2.0 kg (with battery)
Stroke: 25 mm
Drive unit: Brushless direct current motor
Traction power: 10,000 N
Noise emission: L
PA
78.5 dB (A), Measurement uncertainty K=3 dB
Vibrations: < 2,5 m/s², Measurement uncertainty K=1.5 m/s²
1.4 Nosepiece table
Rivet Ø (mm) Rivet material Nosepiece Part no. Jaw pusher Part no.
2.4 Alu 17/18* 143 4976
9 143 5448
3.2
CAP
®
-Alu;
CAP
®
-Cu
17/18* 143 4976
3 and 3.2
Alu, steel,
stainless steel
17/24 143 4955
4 Alu 17/24 143 4955
4 Steel 17/27 143 4973
4 Stainless steel 17/29 143 4974
4.8 and 5 Alu 17/29 143 4974
4.8 and 5 Steel 17/32 143 4975
4.8 and 5 Stainless steel 17/36* 143 4977
6 Alu 17/36* 143 4977
