Type of tool
Standard blind rivet Ø
(mm)
1. Conditions of Use
This blind rivet setting tool may be used only
to set blind rivets, as described in the operating
instructions.
The safety instructions MUST be followed!
2. Safety Notes
Use the tool ONLY to set blind rivets
Never overload the tool: Work within the
stated performance parameters
Never operate the tool without placing the
blind rivet in the hole of the workpiece
or the rivet could come off the tool! Do not
point the tool head towards yourself or
anyone else!
The spent-mandrel container should always
be screwed tightly on to the tool whilst in
operation.
Regularly empty the spent mandrel container:
Overloading may cause damage to the tool.
Do not use the tool as a hammer.
Regularly check the compressed air connec-
tions for 'play' and leakage.
Prior to maintenance and when not in use,
always disconnect the tool from the com-
pressed air supply.
Safety glasses should always
be worn when
using the riveting tool. The use of any per-
sonal protective clothing is always recom-
mended.
Do not exceed the air pressure limit of the
tool.
When not in use, make sure that the tool
cannot fall to the floor.
Repairs should be carried out only by quali-
fied staff. When in doubt, the tool should be
sent back (not dismantled) to the supplier or
to Gesipa.
12
3. Working Range
4. Technical Data
Type of tool
Weight (kg)
Operating pressure (bar)
Stroke (mm)
Air connecting hose Ø (mm)
Spent mandrel container capacity
(spent mandrels)
Air consumption (Liter/rivet)
Setting Power at 5 bar (N)
Hydraulic fluid ISO VG 32 up to 46 (ml)
Noise emission L
pa (dB)
Vibration (m/s
2
)
Compressed air requirement (filtered)
Integrated spent mandrel ejection
Integrated rivet retention
all materials
approx. 100 to 200 acc. to size
TAURUS 2
1,6
5
-
7
18
6
approx.2,3
9.000
approx.30
78
< 2,5
✔
✔
✔
TAURUS 1
1,3
5
-
7
15
6
approx.1,0
4.200
approx.30
77
< 2,5
✔
✔
✔
TAURUS 3
1,9
5
-
7
25
6
approx.4,8
14.000
approx.30
79
< 2,5
✔
✔
✔
TAURUS 4
2,0
5
-
7
19
6
approx.4,8
20.000
approx.30
79
< 2,5
✔
✔
✔
TAURUS 2
up to 5
up to 6 Alu
TAURUS 1
2,4 – 3,2
up to 4 Alu
TAURUS 3
up to 6,4
up to 8 Alu
TAURUS 4
up to 6,4
up to 8 Alu
