12
Ref
Component Description
Microphone Receives sound and voice for the computer.
Camera indicator
(optional)
Lights up when the camera is in use.
IR sensor
(optional)
Detects the infrared energy of objects to form an
image. The sensor flashes red light when in use.
The near infrared (IR) imaging capability allows
you to use Windows Hello face authentication.
Camera lens
(optional)
Allows you to use the camera function.
Camera cover
(optional)
Covers the camera lens.
Slide the camera cover toward the right to use the
camera; slide it toward the left for privacy
protection.
LCD screen Displays the output of the computer.
Select models have the touchscreen feature.
Stereo speaker Sends out sound and voice from the computer.
Touchpad Serves as the pointing device of the computer.
Indicators
Power Lights green when computer is on.
Blinks green when computer is in Sleep mode.
Battery
Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during this
period.
Blinks red (once per second) when the battery’s
capacity is below 10%.
Blinks red rapidly (once per 0.5 second) when
there is a thermal protection problem. Ask for
repair service in case this happens.
