4.9 Handling printouts (option)
An example of a program printout is shown below. The printout
takes place in the configured language. In the example below,
program P02 OP-D is used, which is programmed using menu
selection button , and the language is English.
46-Series
DATE : 2008/06/02
SIGNALS
PROCESS START : 13:28:45
AI07 TEMP INDEPENDENT
MACHINE NAME : 46-Series
CYCLE COUNTER : 12
PARAMETERS
WASH1 TEMP SP 60.0 C
WASH1 TIME 00:01:00
F RINSE TEMP SP 90.0 C
FR TIME 00:01:00
DRY TIME 00:13:00
PROGRAM: P1 OP-SHORT
-----------------------------------------------------
PROGTIME AI07
00:00:00 73.8
START
00:00:00 73.8
DRAIN
WASH 1
00:00:11 73.8
FILL
00:00:21 73.5
HEAT
00:01:20 38.2
DOS START
00:01:21 38.0
DOS STOP
00:01:50 37.9
WASH START
00:06:00 60.1
WASH STOP
00:07:01 60.9
DOS PUMP 1 53.2ml
DRAIN
00:07:02 60.9
RINSE 1
00:08:23 59.8
FILL
00:08:29 59.9
RINSE START
00:09:27 56.2
RINSE STOP
00:10:28 56.2
DRAIN
00:10:28 56.2
FINAL RINSE
00:11:49 55.5
FILL
00:11:59 55.4
HEAT
00:12:58 54.8
DOS START
00:18:29 79.8
DOS STOP
00:18:33 80.1
DISINF START
00:21:01 89.7
DISINF STOP
00:22:02 91.7
DOS PUMP 2 8.8ml
DRAIN DRYING
00:22:03 91.7
DRAIN
00:22:04 91.7
DRY
00:22:43 90.9
PROCESS COMPLETE
00:35:44 70.8
PROCESS OK
000827
4 OPERATION
User Manual Getinge 46-series 23 (56)
<Doc_USR><Doc_6002267102><Rev.B><Lang_en>
