GEZE GC 342 - Fire Protection Kit

Special installation situations GC 342 safety sensor
14
Hinge side:
Extended secondary closing edge protection and wall blanking function inactive.
Opposite hinge side:
Extended main closing edge protection inactive.
X
Use the drive wall blanking.
X
Use mechanical protection for the secondary closing edge if necessary.
7. 2 Fire protection kit
X
Heed the instructions provided by the manufacturer of the re protection door.
X
If the manufacturer of the re protection door permits drill holes <Ø10mm,
use the GC342 re protection kit.
1 2
min. Ø 5 mm
1
