Teach-inGC 342 safety sensor
10 Teach-in
The service mode disables the safety detection of the sensor for
15 minutes and can be useful during installation, mechanical
teach-in of the drive or maintenance work.
X
Give the push button a long push.
Service mode is enabled for 15 minutes.
X
Give the push button another long push.
Service mode is disabled.
Service mode is automatically disabled when the teach-in process starts.
10.1 Explanations master – Slave
DCU
Master
Slave
à The module connected to the DCU is automatically considered to be the
master module.
à The module connected to the master automatically becomes the slave.
Teach-in started on the master
Master and slave are taught.
Teach-in started on the slave
Only the slave is taught.
