GEZE GC 342 User Manual

15
Special installation situationsGC 342 safety sensor
DIPON
1
2
3
4
DIPON
1
2
3
4
2
1
3
2
7.3 Retrot
Makes use of an on site cable possible.
X
Cut the door transmission
cable to the correct length.
X
Strip the 5 wires and connect
them in accordance with the
wiring diagram.
X
Heed the polarity of the
power supply.
SIO
13
1
GND
2/4
2/4
24V
10
TST
SIO
SIS
11
1
GND
24V
10
TST
SIS
13
11
1
4
10
1
Retrofit
Interface
1
1 Type LIYY 5×0.25mm
