Technical data GC 342 safety sensor
36
16 Technical data
Technology Laser scanner, time-of-ight measurement
Detection mode Presence
Max. detection area 4 m (diagonal) with 2% reectivity
(e.g. at W = 1.5 m  max. H = 3.7 m)
Opening angle Door leaf safety: 90° / Pinch zone: 16°
Angle resolution Door leaf safety: 1.3° / Finger protection area: 0.2°
Typical min. object size
à Door leaf safety 10cm for 4m (in Proportion to object distance)
à Pinch zone 2cm for 4m (in Proportion to object distance)
Test body 700mm × 300mm × 200mm (Reference body CA in compliance
with EN16005 and DIN18650)
Characteristics of the transmitter
Infrared LASER Wavelength 905nm; max. output pulse power 25W;
Class1
Power supply 12–24V DC ± 15%
Power consumption ≤ 2W
Response time
à Door leaf safety max. 50 ms
à Pinch zone max. 90 ms
Outputs 2 electronic relays (oating outputs - potential-free)
à Max. switching
voltage
42V AC/DC
à Max. switching
current:
100mA
LED signal 1 two-coloured LED Detection state / Initial state
Dimensions 142mm (W) × 85mm (H) × 33mm (D) (mounting base + 7mm)
Housing material PC/ASA
Colour Black - Aluminium - White
