14. Parts/Subassemblies
Description Code
Actuator PA11, DN 10–25 FC 198 150 127
 DN10–25 FO 198150128
DN 10–25 DA 198 150 129
Actuator PA21, DN 32–50 FC 198 150 130
  FO 198150131
DA 198 150 132
Actuator PA11, DN 15–25 FC 198 150 144
withstrokelimiter  FO 198150145
DA 198 150 146
Actuator PA21, DN 32–50 FC 198 150 147
withstrokelimiter  FO 198150148
DA 198 150 149
Emergency manual override DN 10–25 198 000 500
Emergency manual override DN 32–50 198 000 501
Multifunctional module without limit switches (empty)
Dimensions Code
DN 10/15 167 482 680
DN 20/25 167 482 681
DN 32/40 167 482 682
DN 50 167 482 683
Adapter plate incl. coupling
Dimensions Code
DN 10/15 198 150 556
DN 20/25 198 150 557
DN 32/40 198 150 558
DN 50 198 150 559
Ball valve type 546 see separate datasheet
