16
10 B. Connect electric wires
1. With the tube in place, remove the porcelain inserter, porcelain tube, hex
nut and flat washer from both ends
2. Connect the two ends to the electric wire connectors.
3. Replace flat washer, hex nut, porcelain tube and porcelain inserter
4. Replace side covers and gap wheel
1. Porcelain insert 2. Porcelain cap 3. Hex nut 4. Flat washer 5. Electric wire connector
