Gfp 563TH - Table of Contents

Gfp
563TH
December 2012
2
Table of Contents
Contents Page
1. Introduction …………………………………………………… 3
2. Important Safety Instructions………………………………….. 3
3. Installation Safeguards ……………………………………….. 4
4. General Safeguards……………………………………………. 5
5. Operating Conditions …………………………………………. 6
6. System Components ………………………………………….. 7
7. Control Panel …………………………………………………. 8
8. Packing List ………………………………………………… .. 9
9. Installation
A. Uncrate the machine……………………………………. 10
B. Remove heat tube package……………………………... 10
C. Remove machine from Skid……………………………. 11
D. Assemble machine stand……………………………….. 12
E. Set Machine on stand…………………………………... 13
F. Attach supply support brackets………………………… 14
10. Installing heat tube
A. Insert heat tube…. .…………………………………….. 15
B. Connect electric wires..………………………………… 16
11. Installing Take up Reel ……………………………………….. 17
12. Additional installation items …………………………………. 18
13. Removing Press roller assembly……………………………… 18
14. Loading film ………………………………………………….. 19
15. Threading Film ……………………………………………….. 20
16. Operation ……………………………………………………... 21
17. Roller Gap………….. ………………………………………… 21
18. Roller Gap adjustment…………………………………………. 22
19. Optional Rewind ……………………………………………… 23
20. Troubleshooting ………………………………………………. 24
21. Specifications …………………………………………………. 25
22. Warranty ………………………………………………………. 26
