8. Packing List
Remove all parts from shipping create and boxes. Inspect parts and the machine
carefully. Any missing parts should be reported to the shipper upon receipt of
shipment.
Main Machine Crate Stand Box
Part Quantity Part Quantity
Main Machine 1 Cross beams 2
Swing out shaft assembly 1 Middle beam 1
Rewind tube 1 Left side stand 1
Foot Pedal 1 Right side stand 1
Heat tube 1 8 x100 hex screw 8
Media support brackets 3 8 x 60 hex screw 4
Leveling Feet 4 #8 flat washer 14
Stand anchor bolts (M10) 4 #8 spring spacer 14
Allen wrench 5mm 1 Alignment bracket 2
Film cutter 1 5 x 8 hex screw 4
Operation manual 1 # 5 flat washer 4
8 x 20 hex screw 6 # 5 spring spacer 4
# 8 flat washer 6 Anchor bolts (M8) 2
# 8 spring spacer 6 #8 Nut 2
Allen wrench 4mm 1
Allen wrench 6mm 1
