Gateway
a. IP Address : This field indicates device IP address.
b. MAC Address : This field indicates hardware address of the device.
c. Remote IP : This field indicates IP address of PC to whom Lynx Serial To
Ethernet device has connected.
d. Application Title : This field indicates the name that has been assigned to the
device by the user. If user has not assigned any name to the
device then default name of device will be displayed.
4. Click on Refresh tab to locate the devices that are present in the network.
5. Note the IP address corresponding to the MAC Address & Application Title of the
device.
6. If the device is Factory Default Mode and can't be located in the utility, then change
the IP address of the PC to AutoIP range 169.254.0.1 to 169.254.255.254 & then try
to locate the device.
7. If the device contains some other IP address which is not in the same network as
the PC, device won't be located in the utility. In such case Restore Factory Default
settings of the device using the RST switch as explained in 2.4.2.
8. Exit tab quits the Lynx Locator utility.
Note:
For upgrading Firmware and configuring Driver settings, refer the “Help file” in
the software. Initially Driver1 is configured as Modbus RTU Master and Driver2 as
Modbus TCP server in transparent mode of communication.
