GIC Lynx - Technical Specifications

Page 26
www.gicindia.com
Lynx
Gateway
7. Technical Specifications
Power Supply 12 V to 24 V DC (-10% to +25%).
Max Consumption 2 W max
Management HTTP Web Server and Application software
Protocol Conversion
MODBUS RTU/ASCII
-
MODBUS
TCP
Operation Mode Modbus RTU/ASCII (Slave/Master), Modbus TCP (Client/Server)
Configuration Software
HTTP Web Server & Windows
based Application Software
to Configure
Ports as well as Selection of Protocol Driver
Error Detection IP Conflict, Communication Timeout, Idle Connection, IP Search Mode
Number of Serial Ports 2
Serial Interface
Port1
:
Screw terminals for RS232, RS42
2 and RS485 interface.
Port2: RJ11 for RS232 Interface.
Signals RS232 : RXD, TXD, GND
RS422 :TX+, TX-, RX+, RX-, GND
RS485 : TX+(D+),TX-(D-),GND
Serial Interface Selection
Port1 mode selection using RST switch with MODE LED indication
Serial Communication
Parameters
Parity : Odd, Even, None
Stop Bits : 1,2
Data Bits : 7,8
Baud Rate : 300 to 115.2Kbps
Serial Line Protection
8
-
15KV ESD for all signals , Opto Isolation 2 KV
LAN Interface RJ45, Ethernet 10/100 Mbps
LAN Isolation 1.5KVrms magnetic Isolation
Network Protocols
Supported
ARP, TCP, UDP, HTTP, TFTP, BOOTP, ICMP, DHCP, AutoIP, UPnP. Telnet
Reset Front Panel recessed key for Serial mode selection & Factory Default
Settings
LED
Indication
s
Serial TX and RX, LAN: LINK and Activity, P
ower ON and Error
Operating Temperature 0 to + 55
o
C
Dimensions (W X H X D) 70 X 90 X 58 (mm)
Weight 185 g
Mounting Din Rail/Base
Degree of Protection IP 20
EMI/EMC
ESD
IEC 61000
-
4
-
2
-
Level II,
Radiated Susceptibility ICE 61000-4-3- Level III,
EFT IEC61000-4-4 Level IV
Surge IEC 61000-4-5 Level III
Conducted Susceptibility ICE 61000-4-6- Level III,
Voltage Dips and Interruptions IEC 61000-4-29,
Conducted Emission CISPR 14-1 Class A
Radiated Emission
CISPR 14
-
1 Class A
Approvals CE, ROHS
