2.3. LED Indications
LED Indications for Settings
ERROR LED HB LED MODE LED
Serial Port 1 Interface
Selection
RS 232 Interface
Continuous ON Blinking Green
RS 422 Interface
Continuous ON Blinking Red
RS 485 Interface
Continuous ON Blinking Orange
Factory Default Settings
Continuous ON Blinking -
Firmware Downloading /
No Firmware
Continuous ON Continuous ON NA
LED Indications during Run Time
LED Colour Status Function
HB Green
Blinking Healthy Status
ERROR Red
Blinking
IP Address Search Modes
(100ms ON and 100ms OFF)
IP Address Conflict Error
(500ms ON and 500ms OFF)
Reset Key Fail
(1s ON and 10s OFF)
TX1 Green
Blinking Serial Port-1 Data Transmit
RX1 Green
Blinking Serial Port-1 Data Receive
TX2 Green
Blinking Serial Port-2 Data Transmit
RX2 Green
Blinking Serial Port-2 Data Receive
Port 1
Mode
Green
Continuous ON RS232 selected
Red
Continuous ON RS422 selected
Orange
Continuous ON RS485 selected
Link Yellow
Continuous ON Link (socket connection made)
Activity Orange
Random Flashing Activity (network 10/100mbps)
