GIC Lynx - 7 Technical Specifications

Page 29
www.gicindia.com
Lynx Gateway
7. Technical Specifications
Power Supply
12 V to 24 V DC (-10% to +25%).
Max Consumption
2 W max
Management
HTTP Web Server and Application software
Protocol Conversion
MODBUS RTU/ASCII - MODBUS TCP
Operation Mode
Modbus RTU/ASCII (Slave/Master), Modbus TCP (Client/Server)
Configuration Software
HTTP Web Server & Windows based Application Software to Configure
Ports as well as Selection of Protocol Driver
Error Detection
IP Conflict, Communication Timeout, TCP Idle Connection, IP Search
Mode
Number of Serial Ports
2
Serial Interface
Port1: Screw terminals for RS232, RS422 and RS485 interface.
Port2: RJ11 for RS232 Interface.
Signals
RS232 : RXD, TXD, GND
RS422 :TX+, TX-, RX+, RX-, GND
RS485 : TX+(D+),TX-(D-),GND
Serial Interface Selection
Port1 mode selection using RST switch with MODE LED indication
Serial Communication
Parameters
Parity : Odd, Even, None
Stop Bits : 1,2
Data Bits : 7,8
Baud Rate : 300 to 115.2Kbps
Serial Line Protection
8 - 15KV ESD for all signals , Opto Isolation 2 KV
LAN Interface
RJ45, Ethernet 10/100 Mbps
LAN Isolation
1.5KVrms magnetic Isolation
Network Protocols
Supported
Protocols for Communication : TCP/IP, Telnet(RFC2217)
Std. Protocols used :ARP, HTTP, ICMP, DHCP, AutoIP, BOOTP, UPnP
Protocols used Internally : UDP, TFTP
Reset
Front Panel recessed key for Serial mode selection & Factory Default
Settings
LED Indications
Serial TX and RX, LAN: LINK and Activity, Power ON and Error
Operating Temperature
0 to + 55
o
C
Dimensions (W X H X D)
70 X 90 X 58 (mm)
Weight
185 g
Mounting
Din Rail/Base
Degree of Protection
IP 20
EMI/EMC
ESD
IEC 61000-4-2-Level II,
Radiated Susceptibility
ICE 61000-4-3- Level III,
EFT
IEC61000-4-4 Level IV
Surge
IEC 61000-4-5 Level III
Conducted Susceptibility
ICE 61000-4-6- Level III,
Voltage Dips and Interruptions
IEC 61000-4-29,
Conducted Emission
CISPR 14-1 Class A
Radiated Emission
CISPR 14-1 Class A
Approvals
CE, ROHS
