Gateway
1. Introduction
Lynx Gateway is a Serial to Ethernet Protocol Converter providing communication between
Modbus RTU/ASCII Serial devices & Modbus TCP network devices. It supports various
operating modes & can act as Master or Slave. It supports RS 232, RS 422 and RS 485 &
one Ethernet port providing 10/100Mbps through a standard Ethernet connector. Ethernet
side can be configured either as Client or Server.
It intelligently converts the data between Modbus TCP (Ethernet) and Modbus RTU/ASCII
(serial) devices. By enabling Background communication option it is possible to speed up
the data flow at Serial/Ethernet side thus providing seamless integration of Ethernet and
Serial Modbus devices. It can be configured via web-interface or by Lynx gateway utility. It
also provides remote firmware upgradation.
1.1 Features
Supports Modbus RTU/ASCII (Master/Slave) & Modbus TCP (Client/Server) Protocol
Serial interface supports RS-232, RS 422 and RS485 network.
Ethernet interface supports 10/100Mbps with Auto Negotiation
Ethernet Protocols: BOOTP, TFTP, ARP, DHCP, AUTO/IP, ICMP, TELNET, HTTP server
Serial Baud rate supports from 300 bps to 115.2 Kbps.
Static or dynamic IP configuration via DHCP
Integrated HTTP server for device commissioning and configuration via web browser
Isolation between power supply and communication ports
Remote Firmware Upgrade
LED Indications
1.2 Applications
A few of the different types of serial devices supported by the Serial to Ethernet converter
are listed below:
PLC / HMI / SCADA
Ethernet / Serial based Device monitoring and control system.
Industrial Automation
Data Loggers
Telecommunication Equipment
Security Alarms and Access control systems
Hand Held Instruments
CNC Controllers
