Performance Verification
2500A Series Operation Manual, 34172 Revision C, March 2008
Datasheet 2: Spectral Purity Tests
(Refer to section 4.2.1 for specifications)
Datasheet 3: Maximum-Leveled Power Test
(Refer to section 4.2.2 for specifications)
Test Frequency
Measured Power Level
Harmonics Sub-Harmonics Non-Harmonics
100 kHz
5 MHz
8 MHz
25 MHz
50 MHz
100 MHz
200 MHz
400 MHz
750 MHz
1.5 GHz
3 GHz
7 GHz
15 GHz
23 GHz (2526,2540 series only)
40 GHz (2540 series only)
Test Frequency Measured Maximum-Leveled Power (dBm)
100 kHz
25 MHz
50 MHz
100 MHz
200 MHz
400 MHz
750 MHz
1.5 GHz
3 GHz
7 GHz
15 GHz
23 GHz (2526,2540 series
only)
40 GHz (2540 series only)
