Status Register System
2500A Series Operation Manual, 34172 Revision C, March 2008
2 LIST:FREQ 5000000000.0,5000000000.0,5000000000.0 Add 3 list points to a list with frequency 5 GHz.
3 LIST:POW 8.000,5.000,0.000 Set the power for the 3 list points to 8, 5 and 0
dBm respectively.
4 LIST:DWEL 0.200000, 0.200000, 0.200000 Set the dwell (step) time for the 3 list points to
0.2 seconds.
5 LIST:PRECompute Pre-compute the created list data.
6 LIST:REPeat SWEEP Set the list repeat type to single sweep.
7 TRIGger:SOURce BUS Set the list trigger mode to GPIB (software)
triggering.
8 OUTP ON Turn the RF output on.
9 *TRG Trigger the list.
Sequence Command Description
