- 76 -
Delete an Array
The Delete Array menu option allows for deletion of disk array assignments.
Deleting an existing disk array could result in loss of data. Record all array information including the
arraytype,thediskmembers,andstripeblocksizeincaseyouwishtoundoadeletion.
1. Todeleteanarray,press<3>intheMain Menu to enter the Delete LD Menu. Then highlight the array you
wishtodeleteandpressthe<Delete>keyorthe<Alt>+<D>keys.
2. The ViewLDDenationMenuwillappear(asshowninFigure10)showingwhichdrivesareassignedto
thisarray.Press<Ctrl>+<Y>ifyouaresuretodeletethearrayorotherkeystoabort.
3. Whenthearrayisdeleted,thescreenwillreturntoDelete LD Menu.Press<Esc>toreturntoMainMenu.
Figure 10
View Drive Assignments
The View Drive Assignments option in the Main Menu displays whether the attached hard drives are assigned
to a disk array or are unassigned. Under the Assignment column, drives are labeled with their assigned disk
array or shown as Free if unassigned.
Figure 9
Option ROM Utility (c) 2011 Advanced Micro Devices, Inc.
[ Keys Available ]
[ View Drives Assignments ]
[
h
] Up [
i
] Down [PaUp/PaDn] Switch Page [Ctrl+H] Secure Erase
[ESC] Exit
Port:ID Drive Model Capabilities Capacity (GB) Assignment
01:00 WDC WD800JD-22LSA0 SATA 3G 79.89
[S.M.A.R.T.] Health
Extent 1 79.82 LD 1-1
02:00 WDC WD800JD-22LSA0 SATA 3G 80.2
[S.M.A.R.T.] Health
Extent 1 80.02 LD 1-2
[ Keys Available ]
Option ROM Utility (c) 2011 Advanced Micro Devices, Inc.
[ View LD Denation Menu ]
[ Keys Available ]
[ Drives Assignments ]
Port:ID Drive Model Capabilities Capacity (GB)
01:00 WDC WD800JD-22LSA0 SATA 3G 79.89
02:00 WDC WD800JD-22LSA0 SATA 3G 80.02
Press Ctrl-Y to delete the data in the disk!
or press any other key to abort...
LD No LD Name RAID Mode Drv Capacity(GB)
LD 1 GBT RAID 0 2 80
Stripe Block 64 KB Sector Size 512 B
Read Policy Read Ahead Write Policy WriteBack
