Figure 6
Step 2: The next screen displays the two hard drives you installed. Press <Enter> or <Space> on the two hard
drives respectively to add them into the RAID array. Selected hard drives are marked with an asterisk (Figure
6). Then press <Enter> on NEXT.
Figure 7
Step 3: On the CreateVD menu (Figure 7), use the up or down arrow key to move the selection bar to select
an item and press <Enter> to display options. Set the required items in sequence and press the down arrow
key to proceed to the next item.
Sequence:
1. RAIDLevel: Select a RAID level. Options include RAID 0 (Stripe) and RAID 1 (Mirror).
2. StripeSize: Select the stripe block size. Options include 32 KB, 64 KB, and 128 KB.
3. QuickInit: Select whether to quickly erase old data on the hard drives when creating the array.
4. CacheMode: Select write-back or write-through cache.
5. VDName: Enter an array name with 1~10 letters (letters cannot be special characters).
ENTER/SPACE: Select, ESC: Back/Exit
[ Adapter] [ Devices]
Marvell BIOS Setup (c) 2009 Marvell Technology Group Ltd.
[ RAID ]
RAID Cong
Port Disk Name Size Max Speed Status
* S1 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
NEXT
Select free disks to create
* S0 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
ENTER/SPACE: Select, ESC: Back/Exit
[ Adapter] [ Devices]
Marvell BIOS Setup (c) 2009 Marvell Technology Group Ltd.
[ RAID ]
RAID Cong
Port Disk Name Size Max Speed Status
* S0 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
* S1 SATA: WDC WD800JD-22LSA0 76.3GB SATA 3Gb/s FREE
Select free disks to create
RAID Level :
Max Size (MB): 152478
Stripe Size : 64KB
Quick Init : NO
Cache Mode : WriteBack
VD Name :
Disks ID : 01
NEXT
Create VD
RAID0
