- Check that the bearings do not show flaws or
jamming. If there is, replace it.
- Check that the internal spacer does not show ab-
normal wear. If there is, replace it.
- With a hot air gun heat the seat of the bearing on
the brake calliper side
- With an appropriate tool remove the bearing on
the brake disk side
- Insert the spacer bushing on the brake disk side
Specific tooling
020376Y Adaptor handle
020357Y 32 x 35 mm adaptor
020412Y 15 mm guide
- With a hot air gun heat the seat of the bearing on
the side the rpm indicator detects movement
- Insert the internal spacer with the centring ring
facing to the brake disk side, as shown in the photo
- Use an appropriate tool to insert the bearing on
the rpm indicator movement detector side
Specific tooling
020376Y Adaptor handle
020357Y 32 x 35 mm adaptor
020412Y 15 mm guide
See also
Removing the front wheel
Refitting the front wheel
- When refitting, pay attention in repositioning the odometer drive correctly.
Locking torques (N*m)
Wheel fixing nut 40 to 50 N.m
Handlebar
Runner Purejet Suspensions
SUSP - 3
