Front
Removing the front wheel
- Support the vehicle in such a way that the front
wheel is raised.
- Using two 18 mm hexagonal wrenches remove
the front wheel axle.
Front wheel hub overhaul
- Remove the front wheel
- Keep the wheel level by means of two wooden
wedges
- With the appropriate pliers and tool remove the
wheel bearing on the side the rpm indicator detects
movement, as shown in the photograph
Specific tooling
001467Y014 Pliers to extract ø 15-mm bearings
001467Y009 Driver for OD 42 mm bearings
- Remove the internal spacer
- Use appropriate handle, adaptor and guide and
hit with a mallet to extract the bearing and the
spacer bushing on the brake disk side; insert han-
dle on the side the rpm indicator detects move-
ment, as shown in the photo
Specific tooling
020376Y Adaptor handle
020456Y Ø 24 mm adaptor
020412Y 15 mm guide
Suspensions Runner Purejet
SUSP - 2
