Gilera 633499 - Page 12

Name Torque in Nm
Shock-absorber - frame nut * 20 ÷ 25
Shock-absorber - engine bolt * 33 ÷ 41
Wheel axle pin* 100 ÷ 125
Stand pin 18.5 ÷ 19
Stand screws 18.5 ÷ 19
*: Bloccaggi di sicurezza.
SOSPENSIONE ANTERIORE
Name Torque in Nm
Dado forcella* 20 ÷ 25
Fork screw 20 ÷ 25
Front wheel axle * 45 ÷ 50
*: Bloccaggi di sicurezza.
FRENO ANTERIORE
Name Torque in Nm
Brake fluid pump - hose fitting 13 to 18 Nm
Brake fluid pipe-calliper fitting 20 ÷ 25
Support calliper tightening screw* 20 ÷ 25
Front disc tightening screw* 12 ÷ 15
Oil bleed screw 7 to 10 Nm
*: Bloccaggi di sicurezza.
FRENO POSTERIORE
Name Torque in Nm
Calliper tightening screw 20 ÷ 25
Brake fluid tube- calliper 13 ÷ 18
Brake fluid pump - hose fitting 13 to 18 Nm
Disc tightening screw 6 ÷ 6.5
Rear wheel axle 100 ÷ 125
Rear wheel hub screw 20 ÷ 25
Oil bleed screw 7 to 10 Nm
N.B.
PER ASSICURARE UNA CORRETTA COPPIA DI BLOCCAGGIO, LUBRIFICARE I DADI PRIMA
DEL MONTAGGIO.
GRUPPO MOTORE
Name Torque in Nm
Head tightening nut 10 ÷ 11
Vite spurgo liquido refrigerante 1 ÷ 2
Sensore temperatura 6 ÷ 8
Temperature sensor at the ECU 18 ÷ 22
Crankcase closure screw 12 ÷ 13
Transmission cover closing screw 12 ÷ 13
Pick-up screw 3 ÷ 4
Stator screw 3 ÷ 4
Vite raccordo aspirazione 7 ÷ 8
Starter screw 12 ÷ 13
Mixer screw 3 ÷ 5
Rear hub cap screw 12 ÷ 13
Driving pulley nut 40÷ 44*
Driven pulley nut 40÷ 44*
Characteristics Runner Purejet
CHAR - 6
