ELECRTRICS
Specification Desc./Quantity
1 Instrument panel
2 Headlight assembly
3 Stop switch on front brake
4 Plug with contacts
5 Starter button
6 Right front turn indicator
7 Ignition key-switch
8 Fuel level sender
9 Voltage regulator
10 Coil
11 Spark plug
12 Fuel injector
13 Air injector
14 Water temperature sensor
15 Throttle body pos.
16 Flywheel magneto
Electrical system Runner Purejet
ELE SYS - 2
