Specification Desc./Quantity
8 Starter button
9 Brake light filament 12V-21W
10 Front brake stop light switch
11 Rear stop light switch
12 Battery 12V - 9Ah
13 Fuse 15A
14 Key switch contacts
15 Low-oil warning light switch
Level indicators and enable signals section
LEVEL INDICATORS AND HORN SCHEME
Specification Desc./Quantity
1 CPU
2 Water temperature sensor
3 Resistance 27Ω 0,5W
4 Water temperature gauge
5 7,5A fuse
6 Key switch contacts
7 Fuse 15A
8 Battery 12V - 9Ah
9 Horn button
10 Claxon in c.c.
11 Fuel resreve light
Electrical system Runner Purejet
ELE SYS - 6
