During assembly, observe the installation direction
shown in the figure.
H.V. coil
In order to access the high-voltage coil, remove
the left-hand side fairing.
Saddle opening ECU remote control.
Resetting of the remote control
Electronic control unit ECU
In order to access the immobilizer control unit, re-
move the upper shield back plate.
Nexus 500 euro 3 Electrical system
ELE SYS - 47
