GILES GHM-4 - Overall Dimensions; Specifications

2
IntroductionModel: GHM Warmer Series
.XXX = ±.020
DECIMALS/FRACTIONS ±1/32
OTHERWISE SPECIFIED
TOLERANCES UNLESS
SHEET METAL DEPT.
WELDING/ASSEMBLY DEPT.
DECIMALS
ANGULAR ± 2°
DECIMALS
S
MACHINE SHOP
.XXX = ±.005
.XX = ±.010
.XX = ±.031
T
MONTGOMERY, ALABAMA
R
ENTERPRISES, INC.
REF. FILE INFO: -ECO: ECO1647 - REV: A -FILE: 94677.asm
ANGULAR ± 0.5°
ANGULAR ± 0.5°
B CHANGED DIMS; 44-1/8 WAS 43-7/8, 36-5/8 WAS
36-3/8
0
A RELEASE FOR PRODUCTION 10/07/13 CSY ----
SYM.
28 13/16
731.84
24 13/16
630.24
17
431.51
36 5/8
930.76
44 1/8
1121.26
7
0
°
96 1/4
2444.7
70 5/16
1786.34
57 3/8
1457.15
44 7/16
1128.02
7 1/8
181.46
INCHES [mm]
1.04 Specifications
1.04.1 Overall Dimensions
