24
OperationModel: GHM Warmer Series
This section explains Pan Divider and Steam Pan set-up.
Before installing pan dividers and warming pans, ensure that Heat Controls (Top & Bottom) are in the [OFF] position
(see Section 4.06, Normal Shut-Down) and the unit has adequately cooled.
1. Lift the Front Curved Glass ① and/or open the rear Sliding Doors ②.
2. Install the Long Pan Support Channels
③ at each of the Channel Alignment Brackets ④.
3. Install Short Pan Support Channels ⑤ between each of the Long Pan Support Channels.
DO NOT ADD WATER OR OTHER LIQUID TO THE PAN WELL! The GHM is a dry heat Warmer and the main pan well is not “liquid
tight”. Liquids will likely leak onto the Heating Elements and other electrical components.
4.01 Pan Installation
4
1
3
2
5
Continued on Next Page
