39
Parts List Model: GHM Warmer Series
ITEM NO. PART NO. QTY (MODEL) DESCRIPTION
1 20039 3 (GHM4) 4 (GHM5) 5 (GHM6) 7 (GHM8) STRAP, 3/8” TUBE
2 25352 3 (GHM4) 4 (GHM5) 5 (GHM6) 7 (GHM8) ELEMENT, HFG, 208-240V, GHM
3 20303 3 (ALL) TERMINAL BLOCK, 16-4 AWG, 600V, 85A
4 20304 1 (ALL) TERMINAL BLOCK, GROUND, 16-4 AWG
5 20411 2 (ALL) FUSE HOLDER, DIN RAIL, 600V, 35A
6 21900 2 (ALL) FUSE, 15-AMP, SC-15
7 21175 1 (ALL) CONTACTOR, 50AMP, 1PH, 208/240V
8 90550 1 (ALL) RAIL, DIN, TERMINAL BLOCK, 4.00
9 20607 1 (ALL) BALLAST, T5, 1-2 BULB, 35W, 120/277V
*10 -- 3 (GHM4) 4 (GHM5) 5 (GHM6) 7 (GHM8) THERMOSTAT BULB, *PART OF P/N 23701
11 20320 1 (ALL) TERMINAL BLOCK, GROUND, 24-8 AWG
12 21203 1 (ALL) RELAY, SPST [N.O.], 240V
13 21537 1 (ALL) DIST BLOCK W/FEED, PTFIX 13-POLE, BLACK
14 21542 1 (ALL) DIST BLOCK W/FEED, PTFIX 13-POLE, RED
15 21545 1 (ALL) DIST BLOCK W/FEED, PTFIX 13-POLE, BLUE
16 21496 6 (ALL) END BRKT CLIP, DIN RAIL, PTFIX, NS-35
17 91862 1 (ALL) RAIL, 5.00, DIN, MOUNTING
*18 21548 1 (ALL) JUMPER, TERM. BLOCK, FBS-2-12, RED
7.03 Parts for Element Assembly - Bottom Heat
* 1-Phase Only - must be removed when connected to 3-Phase Power
