Ultrasonic Anemometer
Dx- Diagnostic and Configuration Command (see Appendix L) (Bench Test)
Each of these commands causes a response from the WindObserver 65.
Item
Command
code
Typical response
Type and serial No.
D1
*
12400001
(
where * = E (Unheated unit), F = (Heated unit)
Software version
D2
6.01
Unit configuration D3
Current configuration:
A0 B3 C1 E1 F1 G0000 H2 J1 K1 L1 M2 NA O1 P1 T1 U1 V1 X1 Y1 Z1
Anemometer power
supply voltage
D5 +29.8
Integrity check
D6
See Appendix K (Bench Test)
Reports direction with a
resolution of 1 degree
DR0
Reports direction with a
resolution of 0.01 degree
DR2
The commands DR0, DR2 are only available on units running firmware V6.09
(Serial numbers 20310001 onwards)
Ex - Full Duplex/Half Duplex Mode
Setting
Configuration code
Full duplex
E1
Half duplex
E2
Refer also to Appendix D, Networking.
Fx- Data and Parity Options
Setting
Configuration code
8 bits, no parity, 1 stop bit
F1
8 bits, even parity, 1 stop bit
F2
8 bits, odd parity, 1 stop bit
F3
