Gill WindObserver 65 - Page 54

54
gillinstruments.com
Issue: 8 (Applies to firmware 2387 6.09 onwards)
Document number: 1390-PS-0039
Ultrasonic Anemometer
Note: If changing to F2, using a terminal program then when in configuration mode Type F2 and press Enter, close the
terminal program and open a new one with F2 Even parity settings, then type F and press Enter.
Gx to Gxxxx - Averaging (Digital Outputs only)
Setting
Configuration code
Averaging (Default)
G0000
Enter the required averaging period in seconds as a four-figure number between 0000 and 3600.
Hx - Heating (If fitted)
Heating is autonomous and requires no set-up once activated.
Setting
Configuration code
Disabled
H1
Activated
H2
Jx - Analogue Power-up Tests (N/A)
Kx – NMEA Settings
Setting
Configuration code
NMEA string “IIMWV”
K1
NMEA string “WIMWV”
K2
Lx - ASCII Message Terminator
Setting
Configuration code
CR LF
L1
LF
L2
