69
Issue: 8 (Applies to firmware 2387 6.09 onwards)
Document number: 1390-PS-0039
Alignment Check
Ensure the ICC is assembled correctly on the WindObserver 65. Using Terminal Program, enter Configuration Mode as
described in Section 8.
Enter D6.
A typical report as shown below will be displayed.
D6
ALIGMENT LIMITS: U=2424, 2524
V=2434, 2434
ALIGNMENT U: 2474 *PASS*
ALIGNMENT V: 2484 *PASS*
D6
If ‘Refer to Manual’ is shown check test temperature conditions are 17 to 23 deg C and tested under zero wind condition.
If there has been no significant changes to The WindObserver 65 head configuration then *PASS* will confirm correct
operation.
Alterations to the head geometry can result in a *FAIL* or ‘Insufficient Samples’ message. If this occurs please contact Gill
Instruments.
