16
4.16 MEMORIZED TARAS TLU tLU
• The visor has 5 memorized tares: TLU 1, TLU 2, TLU 3, TLU 4, TLU 5.
• Before you can use this function you must edit and activate the desired tare from the user menu/TLU
• The tare value is locked until it is unlocked with the procedure seen in lock/unlock Tare.
SELECT: To select the tare that we want to activate, this has to be previously created in the editing section
EDIT: To create the tares up to a maximum of 5.
DELETE: To erase all memorized tares.
4.17 ANALOG OUTPUT (ONLY FOR LED DEVICES!) AnALoG
ACCESS TO THE MENU IS POSSIBLE ONLY WHEN THE CARD IS CONNECTED
This card allows the exit of 4-20mA o 0-20mA or 0...+10V o 2…+10V, proportional to the gross weight or the net weight in the scale.
The exit of the current is active and supplies the necessary voltage.
The analog exit is actualized every 50ms and acquires the appropriate value of the weight, converted into in that moment. It is for this
reason that if the filter in the weight is decelerated, the analogical exit is also decelerated.
To do the setting of the parameters, the user must access to:
AnALog
ActivA
Select Yes/No to turn functionality on or off
4-20mA
Requesting full scale (P. MAX) in kg that will deliver 10V.
0-10V
REQUESTING FULL SCALE (U MAX) IN KG THAT WILL DELIVER 10V.
ADJUST
An Min Output for negative weight
An.Zer
Output for zero weight
An MAX Departure for the fund allocated scale (U MAX)
We have to activate the
AnALog function before we start setting
The setup process begins by selecting the operating mode, either 4-20mA or 0-10V depending on the type of output you want. At this point
you must specify the full scale U MAX which must be equal to or less than the full scale of the scale.
When the back of the scale is confirmed, the device starts the establishment of values of the analog exit, or the values of the digital/analog
converter are introduced (comprised between 0 and 65535), for these values it is appropriated a determined value of exit in voltage or
current.
In this configuration the keys of the device acquire the following functions:
An Min ( N. xxxxx)
It establishes the minimum value of the analog exit. With this value we adjust so that the equipment gives a value below 4 mA or 0v. It
also allows us to program the magnitude of the signal when the value loaded on the platform is below zero, belonging to the condition
underload.
An.2 Er( z. xxxxx)
It establishes the magnitude of the analog exit, be that in current or voltage, when the scale displays the minimum weight, which is
going to belong to the Zero of the scale.
An MAX ( M. xxxxx)
It establishes the magnitude of the analog exit, be that in current or voltage, when the scale displays the maximum weight, which is
going to belong to the previous FS programmed.
Press to access the menú ACTIVA.
