30
6.4 ABT VM
Shows the different versions of the program.
6.5 DEFAUL
Restore factory defaults.
7. PRINTER
The available printers are the following ones:
IMP05
IMP27
IMP28
The working of the printer is described below:
When the user presses the key
the weight is printed, with its number of weighing and its corresponding tare if the mode of transmis-
sion is manual (5.1.15).
The user can do successive weights pressing the key
. This process can be done if the system goes first to zero or if a tare is done or if
an additional weight is situated on the platform.
Once the user has done all the needed weights, when pressing the key
the user will obtain the definitive ticket with the number of
weights and the total weight in case that the device has the accumulation option in active mode
If the accumulation mode is automatic, you must choose shipment or Stable 0 or ESTOdE. Or Stable On the other
hand, if the accumulation mode is manual you will have to choose manual shipment.
The printed ticket has 40 characters wide.
7.1 TICKET FORMATS GI400:
FORMATS FOR WEIGHT
F. Imp.1 F. Imp.1 (Numeric keypad only)
Date: 28/02/2018 Time: 11:08:06
Gross: 654 kg
Tare: 0 kg
Net 654 kg
_____________________________________
Weighing Number: #1
Date: 28/02/2018 Time: 11:15:12
T code: 123
Truck: Cuba
Grain: Maiz
Gross: 654 kg
Tare: 10 kg
Net 644 kg
_____________________________________
1
2
3
4
6
5
7
