THE AVAILABLE FUNCTIONS ARE:
CAL AUU
CALCULATION OF THE AVERAGE UNIT WEIGHT
AUU
PIECE COUNTING
CHECt
CHECKWEIGHER
CCt SI
CHECKWEIGHER SIMPLE
by 10
IT SHOWS THE WEIGHT WITH ONE MORE DECIMAL FOR MORE ACCURACY
ACCUMU
ACCUMULATION
Subtot
SUBTOTAL
t CodE
SET PRODUCT CODE
n tiC
SET TICKET NUMBER
WEIGHt
WEIGHT MODE
doSiFi
DOSAGE (only with additional board 4I/40 (relay) (OPTIONAL)
LiMit
LIMITS (only with additional board 4I/4O (relay) (OPTIONAL)
2 rEL
ZERO AND WEIGHT (only with additional board (relay) OPTIONAL)
dSd
FISCAL MEMORY (only with additional board ALIBI) (OPTIONAL)
tLU
MEMORIZED TARAS TLU
AnALog
ANALOG OUTPUTS (Only with analog board OPTIONAL)
FUnCio
FUNCTION MODE
4.1 CALCULATION OF THE AVERAGE UNIT WEIGHT CAL AUU
This function calculates the unit weight of the pieces through the piece counting program. To calculate the average unit weight the user must pla-
ce a number of known pieces on the platform and the press the key . The screen of the display is going to show the message SP.xxxx.
The user must then introduce, using the keys, the number of pieces that make the sample.
To calculate and register the value of the average unit weight the user must press the key .
The terminal shows- during two seconds- the message “WEiUni” on the screen, followed by the unit weight of the piece. After that, the indicator
goes back and shows the number of pieces in the scale.
If the user presses the key and there is no weight on the platform or the weight is inferior to the necessary to calculate it on the screen,
the display is going to show the message “add”. This message indicates that more pieces are needed so that the calculation can be done.
4.2 PIECE COUNTING AUU
This function is used to do the calculation of the pieces loaded on the platform. It does so by taking the programmed average weight (PMU).
The indicator asks for the PMU by showing the message Px.xxxx. The user must introduce the value of the unit weight using the cursor keys.
Press key to confirm.
NOTE: The parts count mode remains active until we access the weight mode.
4.3 CHECKWEIGHER CHECt¡
This function activates the mode “CHECK WEIGHER” or mode goes-not-goes .
The equipment is ready to manage automatically up to 4 zones through limits of weight for each one of them.
When the user accesses the menu CHECt the first parameter s/he must configures is the menu tArgEt: this menu programs the value of the
target of weight that the user wants to achieve. Is the central value of OK zone.
After that the user must choose the type of TARGET between TTYPE1 and TTYPE2.
