EXAMPLE
We are going to take as example a hopper scale with a back of scale of 300kg. Of this scale we only use the range up to 200kg for the exit
of 20mA as this is the maximum capacity of the hopper.
In F.S we will introduce 200kg and we will adjust the value of An_Max so that in the exit we can register 20mA with a multimeter or an
automaton. Next we are going to go to the parameter An_Zer and adjust the value to obtain 4mA in the exit; with this we are going to have a
perfect measuring range of 200kg and 16mA. In the parameter An_Min we are going to introduce a value so that we can read the negatives
to up to the 3mA. In the case that the automaton does not allow it, we will adjust the zero to 5mA. The measuring range is going to be of
200kg and 15mA.
4.18 FUNCTION MENU FUnCio
It is a mode of operation of the user menu. In the next stitch (5. Special functions of the numeric keypad) It is explained, from the operation
of the numeric keypad viewfinders, how this mode works.
The diagram of the left side would be common for all the viewers, and in the detail the operation of each section to manage, items of
weighing, descriptive items, tares and heavy, navigating the menus with the keys with arrows enter and ESC.
5. SPECIAL FUNCTIONS OF THE NUMERICAL KEYBOARD
(FOR MODELS WITH KEYBOARD)
You can enter the following menu by pressing and holding the F key. You can also access each function directly using the direct keys.
The numeric keypad allows us to enter the values of the different menus of the viewfinder much faster than with the keys with arrows, which
still continue working.
Using the numeric keypad it is possible to memorize a maximum of: 400 items of type of weighing (File1), 400 descriptive items (File2),
10 tares and 1000 weight.
Pr. File 1 Filxxx (Select File 1) DIRECT KEYS FUNCTION
CODE
XXXXXX
+ +
Edit item1 menu
DESCRI
24 alphanumeric characters
+ +
Activates the item 1
TARA
TXXXXX
TYPE
WEIGHT
+ +
Deactivates the item 1
CHECKW
TARGET TXXXXX
LOW LXXXXX
HIGHT HXXXXX
ALARM AXXXXX
AUU
PXXXXX
EANCODE 12 alphanumeric characters (NO FUNCTION)
