ENUSER MANUAL GI400 / GI410
1. MECHANICAL DESCRIPTION
1.1 FRONT PANEL
LED
LCD
SIGNS
1 Signal of limits (checkweigher)
2 Signal of level of battery (work with battery optional)
3 Signal of zero
4 Signal of steady weight
5 Gross weight
6 Net weight
7 Weighing range
8 Piece counting
9 Units of measure
10 Numerical keyboard (only 410 models)
11 Signal of relays (only for LCD)
7
2
3 4 5 6 11 1 9 8
