ENUSER MANUAL GI400 / GI410
9.1.2 INTERFACE SERIE RS-232 COM1 Y COM 2
The instrument has serial outputs type RS232
Description of the connector pin-out male exit series RS232-com1
n° pin Description Direction
2 TX (RS232c - transmitter) Exit
3 RX (RS232c - receiver) E
5 GND (signal common)
9.1.3 ADDITIONAL BOARD RS-485 COM2 (DB9)
n° pin Description
1 EARTH
8 RTx-
9 RTx+
9.1.4 ADDITIONAL BOARD 4-20mA/ 0-10V ANALOGUE
n° pin Description
6 GND
7 V
OUT
8 I
OUT
-
9 I
OUT
+
9.1.5 ADDITIONAL BOARD4E/4S(relés) (DB25)
n° pin Description n° pin Description
1 RLY1_C 13 IN1-
14 RLY1_NO 25 IN1+
2 RLY2_C 12 IN2-
15 RLY2_NO 24 IN2+
3 RLY3_C 11 IN3-
16 RLY3_NO 23 IN3+
4 RLY4_C 10 IN4-
17 RLY4_NO 22 IN4+
5 +5V
DC
9 +5V
DC
