ENUSER MANUAL GI400 / GI410
38
9.2.3 OPTIONAL SCHEME RS485
RELES
COM
4-20mA
4-20mA
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10
P1
P2 P3 P4
P5
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10
J2
J2
pin 1 RTX +
pin 2 RTX -
pin 5 EARTH
9.2.4 OPTIONAL SCHEME 4-20MA/ 0-10V ANALOGIC (DB9) 9.2.5 OPTIONAL SCHEME 4I/4O (RELÉS)
RELES
COM
4-20mA
4-20mA
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10
P1
P2 P3 P4
P5
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10
J2
J2
CONNECTOR J2
pin 1 I
OUT
+
pin 2 I
OUT
-
pin 3 V
OUT
+
pin 4 V
OUT
- (GND)
RELES
COM
4-20mA
4-20mA
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10
P1
P2 P3 P4
P5
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10
J2
J2
pin 1 RLY1_C pin 1 IN1 -
pin 2 RLY1_NO pin 2 IN1 +
pin 3 RLY2_C pin 3 IN2 -
pin 4 RLY2_NO pin 4 IN2 +
pin 5 RLY3_C pin 5 IN3 -
pin 6 RLY3_NO pin 6 IN3 +
pin 7 RLY4_C pin 7 IN4 -
pin 8 RLY4_NO pin 8 IN34+
pin 9 + 5V
DC
pin 9 + 5V
DC
pin 10 GND pin 10 GND
