USER MANUAL
Range BEAT-Tr
Edition: January 2016
- MACHINE’S DESCRIPTION Revision: No. 3 14
2.4 TOP AND REAR SIDES
At the top and rear of the of the electrofusion unit are located the following components.
Where: Where:
1 Transport handle 1 Rear cover
2 Power cable 2 Fixing screw
3 Electrofusion cables 3 Seal label
Figure 6a: Top view Figure 6b: Rear view
