USER MANUAL
Range BEAT-Tr
Edition: January 2016
- MODE OF USE Revision: No. 3 20
3.1.7 Entering the Job Number: Only If Enabled (SETUP/JOB = 1).
In case the job’s ID entering is enabled, the unit allows either voluntary or compulsory
entering according to its established setup.
C Voluntary job’s setup: it can be avoided by pressing START/VALIDATE key.
C Compulsory job’s setup: it must be unavoidably entered.
In case of pressing START/VALIDATE key to skip it, the following message is displayed:
JOB:
COMPULSORY
The message is showed up during 3 seconds.
Ð
Entering job number using the barcode
(Code 128 up to 16 characters).
JOB: Start screen.
JOB:
XXXXXXXXXXXXXXXX
Capture by
scanner.
To delete the reading and move to the start
screen, press <STOP>.
If the barcode or reading were incorrect:
JOB:
WRONG DATA
Error message.
Two acoustic signals are emitted and it returns
to the start.
L Entering job number without barcode:
via the keyboard.
Click one of the 4 arrows. The display will show
the following screen:
JOB:
$---------------
Blinking cur-
sor.
Manually enter using the arrow buttons.16
alphanumeric characters.
Press the ¨ and § arrows to move the cursor
to a different field and the © and ª arrows to
select the values.
To delete the reading and pass to the start
screen press <STOP>.
Press the START/VALIDATE key to pass to the next screen.
