3.1.9 Traceability: Only If Enabled (SETUP/TRACEABILITY = 1).
Ò
Entering Traceability data by barcode
(Code 128).
TRACEABILITY: Start screen.
Y PE100 AGRU
200x100 SDR17.6
Capture by
scanner.
The decoding is shown when the barcode is
entered. The traceability text disappears.
To delete the reading and move to the start
screen, press <STOP>.
If the barcode or reading were incorrect:
TRACEABILITY:
WRONG DATA
Error message.
Two acoustic signals are emitted and it returns
to the start.
Click the START/VALIDATE key to pass to the
following screen.
COMPONENT 1: Capture by
scanner.
Now enter the traceability data of Component
1.
PIPE PE100 9052
200 SDR17.6
The Component 1
text disappears.
The decoding is shown when the data are
entered.
L Entering Traceability data without
barcode: via the keyboard.
Click one of the 4 arrows. The display will show
the cursor and the 26 digits with zeros. The far
right-hand side of the top line of the display
shows the digit involved.
TRACEABILITY: 01
$000000000000000000
Blinking cur-
sor.
Press the ¨ and § arrows to move the cursor
to a different field and the © and ª arrows to
select the values.
Once the fitting’s traceability data are entered,
press START/VALIDATE to show the decoding.
I PE100 AGRU
200 SDR11
The traceability
text disappears.
Click the START/VALIDATE key to pass to the
following screen.
COMPONENT 1:
Click one of the 4 arrows. The display will show
the cursor and the 40 digits with zeros.
The far right-hand side of the top line of the
display shows the digit involved.
COMPONENT 1: 01
$000000000000000000
Blinking cur-
sor.
Press the ¨ and § arrows to move the cursor
to a different field and the © and ª arrows to
select the values.
