Global BEAT-Tr - SETUP Option

USER MANUAL
Range BEAT-Tr
Edition: January 2016
Revision: No. 3
MODE OF USE - 37
3.2.4 SETUP option:
Validate the option of the SETUP menu:
INFO
>SETUP
Use the © and ª keys to move to the selected option
and validate with the START key.
This enables access to the following options: LANGUAGE / DATE/TIME / TEMPERATURE
RANGE / OPERATOR / JOB / AUXILIARY DATA / TRACEABILITY / SCRAPER BARCODE /
CLAMP BARCODE.
Use the © and ª keys to move to the selected option and validate with the START key.
C LANGUAGE:
LANGUAGE
EN
The display shows the letters of the active language.
Click the ¨ and § keys to see the other languages loaded in the unit. If you cannot find
the language you want, consult with your distributor.
Click the START/VALIDATE key to accept the option. Click <STOP> to exit this option
without changing the language.
C DATE/TIME:
The following option enables you to update the unit’s date and time.
WARNING !
This option might have restricted access. If enabled, the following screen
will appear initially:
OPERATOR: Enter the supervisor PIN number.
Once the supervisor code has been introduced and the START/VALIDATE button pressed,
the following screen that is directly shown that not having the restriction enabled:
$dd/mm/yy
$hh:mm
dd/mm/yy corresponds to the date and hh:mm to the
time.
Click the ¨ and § keys to move the field and © and ª keys to modify values. Once past
the second line, it is not possible to return to the first. You will have to click <STOP> to
restart the change of date/time. Click the START/VALIDATE key to accept the option once
you have gone over the 5 fields. Click <STOP> to exit this option without making a
modification.
C TEMPERATURE RANGE:
This option allows us to select the ambient temperature range wished according to the
applicable company specification. The temperature limits of the unit are -20ºC and +50ºC
(-4ºF and +122ºF).
