USER MANUAL
Range BEAT-Tr
Edition: January 2016
- MODE OF USE Revision: No. 3 26
Click the START/VALIDATE key to pass to the following screen.
NOTE FOR SOFTWARE VERSION V.
$ 1.32 !
This message could be set to include the enter of the bar-code of the
scraper used. Refer to clause 3.2.4.
Scraper bar-code set as <NO> Scraper bar-code set as <YES>
SCRAPED & CLEANED ?
<YES>
SCRAPED & CLEANED ?
<ENTER BARCODE>
Press START/VALIDATE key to pass Enter the scraper bar-code; then the
to the following screen. following message will appear.
(Does not contemplate it being <NO>. NOTE
: If the bar-code is not available,
press any of the 4 arrow keys. Then the
display will show the message showed
on the left.
NOTE FOR SOFTWARE VERSION V.
$ 1.32 !
This message could be set to include the enter of the bar-code of the
aligning tool if used. Refer to clause 3.2.4.
Aligning tool bar-code set as <NO> Aligning tool bar-code set as <YES>
CLAMP USED ?
<YES>
CLAMP USED ?
<ENTER BARCODE>
<YES> by default. Change to <NO> by Enter the aligning tools bar-code; then
clicking any of the 4 arrow keys. the following message will appear.
Click the START/VALIDATE key. NOTE
: If the bar-code is not available,
press any of the 4 arrow keys. Then the
display will show the message showed
on the left.
PRESS <START>
TO BEGIN
Click the START/VALIDATE key to hear an acoustic
signal and the electrofusion cycle will begin.
If there is a malfunction in the electrofusion process, hot molten
PE/PP can be expelled in rare cases. Therefore, keep at a safe
distance from the fusion point during the electrofusion cycle and do
not connect any other electric equipment during the process.
