USER MANUAL
Range BEAT-Tr
Edition: January 2016
Revision: No. 3
MODE OF USE - 35
C PRINT:
Validate the following PRINT option menu to print the fusion data to a serial printer.
>PRINT
ERASER RECORDS
Connect the unit to a serial printer using a serial
transmission cable.
Printer setup (for the first time):
Before using the serial printer on the electrofusion unit, be sure that the printer’s DIP-
Switches are correctly selected. The setup for a printer Citizen, model CT-S280, is the
following:
1 2345678
ON xx xx
OFF xxx x
The generic setup for an appropriate data print-out on other printer’s brands and models
is:
C XON/XOFF
C 8 bits
C Parity: NONE
C 19200 Bauds
C 1 Stop bit
Printing:
Validate this option to print the options: LAST FUSION / TODAY’S RECORDS / ALL
FUSIONS / SELECT DATE RANGE.
Use the © and ª keys to move to the selected option and the START key to validate. Click
the START/VALIDATE key to print the fusion data.
If you select the last option o f SELECT DATE RANGE, the display will show the following
screen:
$D/MM/YY
dd/mm/yy
DD/MM/YY corresponds to the earliest fusion record
(the first by default) and dd/mm/yy to the latest.
Press the ¨ and § arrows to move the cursor to a different field and the © and ª arrows
to modify the values. Once past the second line, it is not possible to return to the first.
You will have to click <STOP> to restart the range selection. Click the START/VALIDATE
key to print.
Select any of the four options for the display to show the following message while the
printing is under way.
PRINTING RECORDS... When data delivery to printer has terminated, the
display returns to the option selected at the start.
Click <STOP> key to exit this option.
