GLOBALJIG INTERNATIONAL S.r.l.
9
2.6 “KOALA” lift orientation
The front of the lift (as indicated in the diagram) is the side containing the “lifting jacks” and the outlet for
the connections to the control unit.
Always position the heaviest portion of the load toward the front of the lift, as this will ensure the
maximum stability of the platform.
ATTENTION:
The LP is designed for the heaviest part of the load to be sustained at the front.
FRONT
HYDRAULIC
JACKS
