● one of the available specific pattern steps (static indexing = DMX values 128 …
255).
Note
Bear in mind that different patterns can have a different number of pattern steps. This
can affect synchronization between fixtures, for example, if you run different patterns
in multiple fixtures.
Pattern Step Crossfade
The Pattern Step Crossfading channel lets you choose how one step in a pattern
should change into the next step. This change can be a snap, a normal crossfade or a
fade with tail (quick fade In and variable long fade out).
Pattern Transition
The Pattern Transition channel lets you choose how a Pattern A should change into
Pattern B. This change can be a snap, a soft crossfade, a Fade Over Blackout (FOB) or
Fade Over Full (FOF).
Special/Control DMX channel
The Special/Control DMX channel lets you change fixture settings and perform a fixture
reset from the control desk (a possibility that can be very useful during a show or for a
specific scene). To apply a command on the Special/Control channel, you must hold
the command for the time indicated in the DMX channel index section at the end of
this user manual.
To trigger a reset using the Special/Control channel, you must send the DMX value for
this function for 3 seconds. If you want to trigger an additional reset using the
Special/Control channel, you must first move away from the Reset DMX value and
then return to this value. This requirement to change DMX values eliminates the risk of
the fixture entering an unwanted Reset loop if it is patched wrongly.
Accessory channels 1and 2
It is possible to install optional electromechanical effect modules on the front of the
impression X5 head. These modules can be supplied with power and control data
using the power and data connection available on the back of the head. The two
accessory channels supply two sets of DMX control data at this connection.
