GLP impression X5 - Page 53

German Light Products® DMX MODE 2
Rev. 20220720-01 53
Sub Module: Second Layer Control (continued)
Pattern Step 48
222
223
87.1
87.5
Pattern Step 49
224
225
87.8
88.2
Pattern Step 50
226
227
88.6
89.0
Pattern Step 51
228
229
89.4
89.8
Pattern Step 52
230
231
90.2
90.6
Pattern Step 53
232
233
91.0
91.4
Pattern Step 54
234
235
91.8
92.2
Pattern Step 55
236
237
92.5
92.9
Pattern Step 56
238
239
93.3
93.7
Pattern Step 57
240
241
94.1
94.5
Pattern Step 58
242
243
94.9
95.3
Pattern Step 59
244
245
95.7
96.1
Pattern Step 60
246
247
96.5
96.9
Pattern Step 61
248
249
97.3
97.6
Pattern Step 62
250
251
98.0
98.4
Pattern Step 63
252
253
98.8
99.2
Pattern Step 64
254
255
99.6
100.0
31
Pattern step
crossfading
(from one step to
next)
Off (no crossfading, Snap)
0
9
0
3.5
0
Snap
Crossfading:
Snap → min. Xfade → max. Xfade
(fade in and fade out times are
identical)
10
127
3.9
49.8
Fade
Off (no crossfading, Snap)
128
137
50.2
53.7
Snap
Crossfading with tail:
Snap → min. Xfade with tail → max.
Xfade with tail
(fade in time is shorter than fade out
time)
138
255
54.1
100
Fade
32
Pattern transition
(from one pattern
to next)
Off (snap from one pattern to next)
0
9
0
3.5
0
Snap
Normal transition (snap → fade 5s)
10
63
3.9
24.7
Fade
Off (snap from one pattern to next)
64
73
25.1
28.6
Snap
FOB (Fade Over Blackout) transition
(snap → fade 5s)
74
127
29.0
49.8
Fade
Off (snap from one pattern to next)
128
137
50.2
53.7
Snap
FOF (Fade Over Full) transition
(snap → fade 5s)
138
191
54.1
74.9
Fade
No function
192
201
75.3
78.8
No transition time - reserved for
future use
202
255
79.2
100.0
33
Red intensity
Intensity 0 → 100%, Pixels 1 – 19,
Second Layer
0
255
0
100
0
Fade
34
Green intensity
Intensity 0 → 100%, Pixels 1 – 19,
Second Layer
0
255
0
100
0
Fade
35
Blue intensity
Intensity 0 → 100%, Pixels 1 – 19,
Second Layer
0
255
0
100
0
Fade
