GME TX4500 - Tone and Frequency Charts; CTCSS Frequency Chart Details; DCS Tone Code Chart Details

PA G E 2 4 I N S T R U C T I O N M A N U A L T X 4 5 0 0
CTCSS TONE FREQUENCY CHART CTCSS Frequency shown in Hz
50 Tone
Set
38 Tone
Set
Frequency 50 Tone
Set
38 Tone
Set
Frequency 50 Tone
Set
38 Tone
Set
Frequency
1 1 67.0 18 17 118.8 35 - 183.5
2 - 69.4 19 18 123.0 36 30 186.2
3 2 71.9 20 19 127.3 37 - 189.9
4 3 74.4 21 20 131.8 38 31 192.8
5 4 77.0 22 21 136.5 39 - 196.6
6 5 79.7 23 22 141.3 40 - 199.5
7 6 82.5 24 23 146.2 41 32 203.5
8 7 85.4 25 24 151.4 42 - 206.5
9 8 88.5 26 25 156.7 43 33 210.7
10 9 91.5 27 - 159.8 44 34 218.1
11 10 94.8 28 26 162.2 45 35 225.7
12 11 97.4 29 - 165.5 46 - 229.1
13 12 100.0 30 27 167.9 47 36 233.6
14 13 103.5 31 - 171.3 48 37 241.8
15 14 107.2 32 28 173.8 49 38 250.3
16 15 110.9 33 - 177.3 50 - 254.1
17 16 114.8 34 29 179.9 - - -
DCS TONE CHART
DCS CODE DCS CODE DCS CODE DCS CODE DCS CODE DCS CODE
1 023 12 065 23 132 34 205 45 255 56 331
2 025 13 071 24 134 35 212 46 261 57 332
3 026 14 072 25 143 36 223 47 263 58 343
4 031 15 073 26 145 37 225 48 265 59 346
5 032 16 074 27 152 38 226 49 266 60 351
6 036 17 114 28 155 39 243 50 271 61 356
7 043 18 115 29 156 40 244 51 274 62 364
8 047 19 116 30 162 41 245 52 306 63 365
9 051 20 122 31 165 42 246 53 311 64 371
10 053 21 125 32 172 43 251 54 315 65 411
11 054 22 131 33 174 44 252 55 325 66 412
